Dn1(mm) | D1(mm) | Dn2(mm) | D2(mm) | L(mm) | L2(mm) | L2(mm) |
63 | 80 | 50 | 65 | 125 | 50 | 45 |
75 | 96 | 50 | 65 | 140 | 55 | 45 |
63 | 80 | 145 | 55 | 50 | ||
75 | 115 | 50 | 65 | 155 | 65 | 45 |
63 | 80 | 160 | 65 | 50 | ||
75 | 95 | 160 | 65 | 55 | ||
110 | 140 | 50 | 65 | 160 | 75 | 45 |
63 | 80 | 160 | 75 | 50 | ||
75 | 95 | 165 | 75 | 55 | ||
90 | 115 | 170 | 75 | 65 | ||
160 | 120 | 90 | 115 | 230 | 75 | 65 |
110 | 140 | 230 | 95 | 75 | ||
200 | 250 | 110 | 140 | 295 | 105 | 115 |
160 | 200 | 250 | 105 | 100 | ||
250 | 300 | 110 | 140 | 275 | 120 | 130 |
160 | 200 | 275 | 120 | 135 | ||
200 | 250 | 275 | 120 | 145 | ||
315 | 315 | 110 | 140 | 310 | 140 | 130 |
160 | 200 | 310 | 140 | 135 | ||
200 | 250 | 310 | 140 | 145 | ||
200 | 300 | 310 | 140 | 155 | ||
400 | 470 | 110 | 140 | 340 | 155 | 130 |
160 | 200 | 340 | 155 | 140 | ||
200 | 250 | 340 | 155 | 145 | ||
250 | 300 | 340 | 155 | 155 | ||
315 | 370 | 340 | 155 | 160 |
